Polyester Melt Blown Filter Cartridge
The FCE series Polyester Melt-blown Filter Cartridge has properties that polypropylene filter cartridges do not have, such as high temperature resistance, and can be used for processes such as petroleum chemical solvent filtration. In addition, it has the benefits as true gradient depth filtration, extremely low pressure loss, high removal ratings and high void volumes, making the polyester product the best choice for many major filter users.
Product Features:
- Graded density structure for maximum dirt holding capacity
- Rated for temperatures up to 120℃
- Excellent chemical compatibility with petroleum oils & acid solution
- High void volume, resulting in low differential pressure and excellent dirt holding capacity
- No resins, binders or anti static agents to ensure minimal extractables
- Formed by thermal bond without use of any binders and adhesives
- Maximum operating pressure drop: 20°C 4.2kg/cm²
- Maximum operating temperature: 120°C
- D(outside):63mm D(inside): 28mm
Applications:
- Filtration of edible and petroleum oils
- Filtration of acid solution
- Paint coatings
- Food and beverage
Specification Code:
| Filter Element Type | Filter Element Length | Filter Element Connection Type | Seal Ring Material | Filtration Accuracy (μm) | Center Core |
| FCE – Polyester Depth Melt Blown | 10 – 10″ | 3, 4, 6, 7 | E – EPDM | 1 | Y – Nylon |
| 20 – 20″ | For details, see description for filter element connection type selection | B – Buna N | 5 | N – None | |
| 30 – 30″ | U – No Shim | 10, 25 | |||
| 40 – 40″ | S – Silicon | 50, 75 | |||
| V – Viton | 100 |
