• Side-entry inlet and removable top cover, prevent filtrate spillage during opening.
• Top cover can be opened by various modes – opening direction and mode can be flexibly selected according to field conditions
• Top cover handle – ergonomic design for easy operation
• Special pressure ring design for fully compressing filter-bag
• Eye bolt – for easy and reliable opening and closing

• Electrolytic polished supporting basket – for sufficiently supporting filter-bag for easy cleaning
• Stable adjustable supporting legs
• Two sizes of bags available: No.1 and No. 2 casting top cover

Parameter	SIZE 2	SIZE 1
Inlet	2″BSP / NPT
Outlet	2″BSP / NPT
Vent valve	1/2″Rc/ NPT
Sewage outlet	1/2″Rc/ NPT
Hydrotest	ECS:14.3 bar
Design Temperature	-10/900C
Filter volume	28L	17L
Seal ring	BUNA SILICON EPDM TEFLON VITON
Nuts & bolts	C.S + Zinccoat
Filter Material	SS304 SS316L
Net weight	ECS:23KG	ECS:19KG

Product Code

No.	Material	No. of Bags	Filter Bag Size	Inlet/Outlet Bore	Design Pressure	Inlet/Outlet Bore	Seal Ring Material	Customized
ILB	S-ss316L	01	01	A-ANSI	10-10bar	100-4″	B-BUNA
	E-ss304		02	D-DN	20-20bar	150-6″	T-TEFLON
			03	N-NPT			E-EPDM	ECS
			04				S-SILICA	ECT
							V-VITON
